High speed crushing granulator

Higao Tech offer high quality pharmaceutical high speed crushing granulator for pellet production in china. Crushing granulator machine is used to crush and adjust the shape of granules that comes from the drying equipment.
  • item no.:

    CG series crushing granulator
  • Payment:

    T/T 30% deposit and 70% before shipment
  • product origin:

    made in china
  • Color:

    Shining Polish or Matte Shinning Polish
  • shipping port:

    Shanghai Port
  • Lead Time:

    30 Days
  • Product Detail
  • specification

High speed crushing granulator


Higao Tech offer high quality pharmaceutical high speed crushing granulator for pellet production in china. Crushing granulator machine is used to crush and adjust the shape of granules that comes from the drying equipment.


1. Introduction:
High speed crushing granulator is used to crush dried blocked material into required shape and size according to customers demand.
Pharmaceutical crushing granulator machine for pellets production is widely used in pharmaceutical, chemical and foodstuff industries.
High speed crushing granulator High speed grinding granulator cone mill


2. Structure and Features:

Its reasonable screen and high speed rotor, which can crush big fragile blocked materials into granules.
The final size can be adjusted by changing the screen.
Featured with high capacity, low dust, low noise, easy cleaning.
cone mill to make granules cone mill for food granulation cone mill for pharmaceutical granulation

CG Series High Speed Crushing Granulator of HIGAO TECH

Model

Capacity

Spring Length

Size of Sieve

Motor/speed

Dimension(L×W×H)

Weight

CG-80

50~100kg/h

185mm

Ф1~8mm

0.55kw/ 1500/3000rpm

650×450×1000mm

60kg

CG-120

100~200kg/h

185mm

Ф1~8mm

1.1kw/ 1000/1500rpm

1000×800×1200mm

150kg

CG-160

150~300kg/h

185mm

Ф1~8mm

1.5kw/ 1000/1500rpm

1060×850×1350mm

180kg

CG-200

200~400kg/h

185mm

Ф1~8mm

2.2kw/ 800/1000rpm

1100×1000×1500mm

250kg

Contact Us For A Quote
If you have any inquiry or requirement,please leave a message,we will reply as soon as possible within 24 hours.
