Granulating Equipment

/Double roller compaction granulator

Double roller compaction granulator

Higao Tech produce good quality double roller compaction granulator machine for making chemical fertilizer pellets in china. Equipped with a swing granulator to crush the flakes into granules to form a better shape.

item no.:
DG series dry granulator
Payment:
T/T 30% deposit and 70% before shipment
product origin:
made in china
Color:
Shining Polish or Matte Shinning Polish
shipping port:
Shanghai Port
Lead Time：
30 Days

contact now

Product Detail
specification

Double roller compaction granulator

Higao Tech produce good quality double roller compaction granulator to make chemical fertilizer pellets in china. It can make flaky or sheeted granules. Usually there will be a swing granulator under the output of double roller compaction granulator to crush the flakes into granules to get a better shape.

1. Introduction and Application:
Double roller compaction granulator machine is a new granulating equipment to make granules directly from the dry powder with crystallized water inside materials itself, which is widely applied in pharmacy, foodstuff, and chemical fields.
Especially suitable for the granulation of those materials which can not be done by wet method granulation. The final granules can be pressed into tablets or capsules, etc.

dry powder roller press granulator machine

Double roller compaction granulating machine

2. Structure and Features:
Double roller compaction granulator machine consists of feeding system, screw conveying system, roller squeezing system, crushing system, granulating system, water cooling system.
Designed to meet GMP standard by absorbing and digesting the advanced technology from Germany.
High efficiency, reasonable structure, easy to move, no dust, low noise, easy to clean and maintain.
dry powder compaction granulator

DG Series Double Roller Compaction Granulator of HIGAO TECH
Model	Capacity	Feeding size	Size of Granules	Hopper	Roller size	Max roller pressure+ hydraulics	Conveyor/roller/granulator/oil pump	Weight
DG-20	1~5kg/h	0.4~6mm	0.3~2mm	2L	Ф60×20mm	6Mpa/8Mpa	0.55kw/0.55kw/0.55kw/0.55kw	400kg
DG-40	5~20kg/h	0.4~6mm	0.3~2mm	3L	Ф120×40mm	6Mpa/8Mpa	0.75kw/1.5kw/0.55kw/0.55kw	800kg
DG-80	20~60kg/h	0.4~6mm	0.3~2mm	3L	Ф120×80mm	10Mpa/15Mpa	1.1kw/1.5kw/0.55kw/0.55kw	1500kg
DG-120	30~100kg/h	0.4~6mm	0.3~2.5mm	5L	Ф120×50mm	10Mpa/15Mpa	1.1kw/2.2kw/0.75kw/0.75kw	2000kg
DG-150	40~120kg/h	0.4~6mm	0.3~2.5mm	5L	Ф150×50mm	10Mpa/15Mpa	1.1kw/3kw/0.75kw/0.75kw	2500kg
DG-200	50~200kg/h	0.4~6mm	0.3~2.5mm	8L	Ф200×50mm	15Mpa/20Mpa	1.5kw/4kw/1.1kw/1.1kw	3000kg

Hot Tags: double roller compaction granulator machine roller granulator machine dry granulation machine

Previous : Dry and wet powder mixing high shear mixer granulator
Next : High speed crushing granulator

If you have any inquiry or requirement，please leave a message，we will reply as soon as possible within 24 hours.

Subject : Double roller compaction granulator
