plastic crusher machine

Higao Tech manufacture good quality plastic crusher machine with best quality and cheap price in china. Powerful plastic crusher machine has wide application for crushing and recycling various plastic products and old materials.
  • item no.:

    PC series plastic crusher
  • Payment:

    T/T 30% deposit and 70% before shipment
  • product origin:

    made in china
  • Color:

    Shining Polish or Matte Shinning Polish
  • shipping port:

    Shanghai Port
  • Lead Time:

    30 Days
  • Product Detail
  • specification
Higao Tech manufacture good quality plastic crusher machine with best quality and cheap price in china. Powerful plastic crusher machine has wide application for crushing and recycling various plastic products and old materials.

1. Applications:
Plastic crusher machine is applied as a recycling device for plastics suitable for recycle plastic casing, thin plastic tube, injection and mould sector, bottle plastics and shell plastics. Mainly used in PVC, polypropylene, nylon, engineering plastics and waste products of polymer foam soft material or injection nozzle outlet.
Such as the replacement of corresponding sieve plate, and adjust the gap of the crushing blades, plastic crusher machine can also break all kinds of blowing film, sheet, plate, box, blow molding and other plastic products.
plastic crusher machine plastic crushing granulator machine
2. Characteristics:
(1) Steel structure body, cast steel knife rest, holder steel cutters, avoiding crack.
(2) Ladder style cutters improves the shear force and enhances crushing efficiency.
(3) Heavy duty bearings and oil seal and sound barrier can reduce vibration and noise effectively and protect the materials being contaminated from grease.
(4) Installed knives cleaning protective device to keep operator safe when cleaning crushing knives inside.
(5) Crushing knives can be sharpened again to reuse when they are blunt or dull.
(6) The distance between crushing knives(or called crushing blades or rotors) is adjustable.
(7) A protective switch is put in the feeding mouth to protect the operator.
(8) Motor is equipped with over loading protective device to protect motor and operator.
(9) Crushing knives, sieve or screen and discharging port are designed separately, easy to dismantled and clean.
(10) Equipped with sliding wheels which can be moved easily.
(11) According to the diversification of the crushed materials, different structures of crushing rotors are available. Such as step arrangement claw type rotor blade, flat blade rotor, V type blade rotor.
plastic shredder machine plastic shredding machine

plastic and rubber pulverizing machine plastic crushing mill

PC Series Plastic Pulverizer of HIGAO TECH

Model

Capacity

Inlet hopper size

Output size

Motor

No. Of Fixed cutter

No. Of Flexible cutter

Dimension(L×W×H)

PC-180

30~80kg/h

190×165mm

Depends

2.2kw

2pcs

9pcs

65500×1000mm

PC-230

50~100kg/h

210×235mm

Depends

4kw

2pcs

6pcs

75600×1200mm

PC-300

100~250kg/h

310×245mm

Depends

5.5kw

2pcs

9pcs

900×800×1250mm

PC-400

200~400kg/h

410×260mm

Depends

7.5kw

2pcs

12pcs

950×900×1300mm

PC-500

350~800kg/h

510×320mm

Depends

11~18.5kw

2/4pcs

6/9/15pcs

1200×1000×1800mm

PC-600

450~900kg/h

610×350mm

Depends

15~22kw

4pcs

6/18pcs

1300×1200×1700mm

PC-700

550~1000kg/h

710×360mm

Depends

18.5~30kw

4pcs

21pcs

1500×1250×1900mm

PC-800

700~1000kg/h

810×525mm

Depends

30~37kw

4pcs

6/15/24pcs

1400×1400×1700mm

PC-1000

1000~1500kg/h

1020×810mm

Depends

55kw

4pcs

9/18pcs

2000×2000×2650mm

Contact Us For A Quote
If you have any inquiry or requirement,please leave a message,we will reply as soon as possible within 24 hours.
